3.4 Performance characteristics
General
· DIN rail device with dimensions of
(WxHxD) 71.5 x 90 x 46 mm
· Mounting on DIN rail 35 mm, 4 TE
· Connection via screw terminals
· Setting via coding switch
· 3 voltage measurement inputs (300 V, CAT III)
· 3 current measurement inputs (via current trans-
former)
· Data memory 4 MByte flash
· RS-485 interface (Modbus RTU)
· Clock and battery
Measurement uncertainty
· Active energy, measurement uncertainty class
0.5S S for ../5 A transformers
· Active energy, measurement uncertainty class 1
for ../1A transformer
· Reactive energy, class 2
Measurement
· Measurement in TN and TT networks
· Continuous sampling of the voltage and
current measurement inputs
· True effective value measurement (TRMS)
· Measurement of reactive distortion power
· Sampling frequency 5.4 kHz
· Measurement of positive, negative and zero se-
quence component
· Measurement of harmonics current, 1st to 40th
for U and I
· Measurement of distortion factors THD-U /THD-I
3.5 EU conformity declaration
Please see the EU declaration of conformity post-
ed at www.janitza.de for the laws, standards and
directives applied by Janitza electronics GmbH for
the devices. The CE conformity marking require-
ments for the device arise from the EU conformity
declaration and the laws, standards and directives
mentioned therein.
3.6 FCC Declaration of Conformity
The device:
· complies with Part 15 of the FCC Rules for Class
B digital devices (limits to protect against harmful
interference in a residential installation).
· generates, uses and can radiate high-frequency
energy
· can cause harmful interference to radio commu-
nications if not installed and used properly. There
is no guarantee that interference will not occur in
a particular installation.
If there is radio or television reception interference,
which can be determined by turning the device on
and off, proceed as follows:
· Align or reposition the receiving antenna.
· Increase the distance between the device and the
radio/television receiver.
· Connect the device and the radio/television
receiver in different circuits.
· if necessary, contact Janitza support or a radio/
television technician.
Code of Federal Regulations, Title 47, Part 15,
Subpart B - Unintentional Radiators.
