UMG 96RM-M
Ammeter
If you want to measure the current not only with the UMG
96RM-M but also with the ammeter, the ammeter must
be connected in series with the UMG 96RM-M.
Fig. Current measurement with an additional
ammeter (example).
UMG
S2
I
S
1
Einspeisung
Supply
Verbraucher
Consumer
A
(k)S
1 S2(l)
P
2(L)(K)P1
