Measured value relay
All measured values are calculated every 10/12 periods
and can be recalled once per second on the measured
value displays. Two methods are available for retrieving
the measured value displays:
• The automatically changing display of selected
measured values, referred to here as measured value
relaying.
• Selection of a measured value display using buttons
1 and 2 from a preselected display profile.
Both methods are simultaneously available. Measured
value relaying is active if at least one measured value
display is programmed with a changeover time greater
than 0 seconds.
If a button is pressed, the measured value displays
of the selected display profile can be browsed. If no
button is pressed for about 60 seconds, the device
switches to the measured value relay and the measured
values from the selected display change profile
of the programmed measured value displays are shown
one after the other.
Changeover time (addr. 039)
Adjustment range: 0 .. 60 seconds
If 0 seconds are set, no changeover takes place between
the measured value displays selected for the measured
value relay.
The changeover time applies for all display change
profiles.
Display change profile (addr. 038)
Adjustment range: 0 .. 3
0 - Display changeover profile 1, by default.
1 - Display changeover profile 2, by default.
2 - Display changeover profile 3, by default.
3 - Customised display changeover profile.
Measured value displays
After return of the power supply, the UMG 96RM-P/
-CBM shows the first measured value panel from the
current display profile. In order to keep the selection
of measured values to be displayed arranged in a clear
manner, only one part of the available measured values
is pre-programmed for recall in the measured value dis-
play by default. A different display profile can be select-
ed if other measured values are required to be shown on
the UMG 96RM-P/-CBM display.
