Time recording
The UMG 96RM-P/-CBM records the operating hours
and the total running time of each comparator
• where the time of operating hours is measured with
a resolution of 0.1 h and is displayed in hours or
• the total running time of the comparator is represented
in seconds (when 999999 seconds is reached,
the display changes to hours).
For the querying of measured value displays, the times
are marked with the numbers 1 to 6:
none = operating hours meter
1 = total running time, comparator 1A
2 = total running time, comparator 2A
3 = total running time, comparator 1B
4 = total running time, comparator 2B
5 = total running time, comparator 1C
6 = total running time, comparator 2C
A maximum of 99999.9 h (= 11.4 years) can be shown
on the measured value display.
Operation backlight (addr. 036)
The operation backlight is activated by pushing the ap-
propriate button, or with a restart.
Standby backlight (addr. 747)
This backlight is activated after an adjustable period of
time (addr. 746). If no button is pressed within this peri-
od, then the device switches to the standby backlight.
If buttons 1 - 3 are pressed, the device switches to
the operation backlight and the defined period of time
begins again.
If the brightness settings for the two backlights are set to
the same value, then no change is discernible between
the operation and standby backlights.
Addr. Description Setting
range
Default
setting
036 Brightness for
operation backlight
0 .. 9 6
746 Period of time after
which the backlight will
switch to standby
60 .. 9999
Sek.
900
Sek.
747 Brightness for
standby backlight
0 .. 9 0
0 = min. brightness, 9 = max. brightness
