Janome J30 - Mechanical Adjustment; Presser Bar Height

8
6.0 mm
MECHANICAL ADJUSTMENT
PRESSER BAR HEIGHT
Thedistancebetweenthebottomofthepresserfootinuppositionandtheneedleplateshouldbe6.0mm.
1. Removethefaceplateandneedle.
2. Lowerthefeeddogbelowtheneedleplate.
 Placeablock6mmthickunderthe presserfootandlowerthepresserfootlifterw.
3. Loosenthesetscrewq.Raisethepresserfootlifterandtightenthesetscrewqrmly.
 Attachtheneedleandfaceplate.
NOTE:
Makesurethatthepresserfootshouldbeparalleltothefeeddogslotsintheneedleplate.
q
Feed dog slots
Presserfootshouldbeparallel
tothefeeddogslots.
w
