Janome J30 - Printed Circuit Board a

25
PRINTED CIRCUIT BOARD A
TO REMOVE:
1. Removethefrontcover.(Seepage6.)
2. PulloutconnectorsfromtheprintedcircuitboardA.
3. Removethescrews(4pcs.)andtheprintedcircuitboardA.
TO ATTACH:
1.Followtheaboveproceduresinreverse.
NOTE:
Donotdisconnecttheconnectorsbypullingoncord.
Todisconnect,grasptheconnector,notthecord.
REPLACING THE ELECTRONIC COMPONENTS
PrintedcircuitboardASetscrews
