Janome J30 - Printed Circuit Board L

28
Connector(Blue)
PRINTED CIRCUIT BOARD L
TO REMOVE:
1. Removethefrontcover.(Seepage6.)
2. PulloutconnectorsfromtheprintedcircuitboardA.
3. RemovethescrewandLEDcover.
4. RemovetheprintedcircuitboardL.
TO ATTACH:
1.Followtheaboveproceduresinreverse.
NOTE:
Donotdisconnecttheconnectorsbypullingoncord.
Todisconnect,grasptheconnector,notthecord.
REPLACING THE ELECTRONIC COMPONENTS
Setscrew
PrintedcircuitboardL
inLEDcover
