Janome J30 - Rear Cover

7
CHANGING EXTERNAL PARTS
REAR COVER
To remove:
1.Removethefacecoverandfree-armcover(Seepage4and5).
2.Removethesetscrewsq(2pcs.)andthesetscrewsw(3pcs.).
3.Removethesetscrewse(4pcs.)andbackcoverr.
4.Removethesetscrewst(2pcs.).
6.Disengagethefrontcoverandrearcoverhooks.
7.Removethefrontcover.
To attach:
5.Followtheaboveproceduresinreverse.
