Janome J30 - Printed Circuit Board F1

27
PrintedcircuitboardF2
LEDcover
Connector(White)
PRINTED CIRCUIT BOARD F1
TO REMOVE:
1. Removethefrontcover.(Seepage6.)
2. PulloutconnectorsfromtheprintedcircuitboardA.
3. Removethescrews(2pcs.)andLEDcover.
4. RemovetheprintedcircuitboardF2.
TO ATTACH:
1.Followtheaboveproceduresinreverse.
NOTE:
Donotdisconnecttheconnectorsbypullingoncord.
Todisconnect,grasptheconnector,notthecord.
REPLACING THE ELECTRONIC COMPONENTS
Setscrews
