SWITCHING REGULATOR UNIT
TO REMOVE:
1. Removethefrontcoverandtherearcover.(Seepages6and7.)
2. Removethesetscrewsq(3pcs.)andtheswitchingregulator.
3. Removethesetscrewsw(4pcs.).
TO ATTACH:
4. Followtheaboveproceduresinreverse.
REPLACING THE ELECTRONIC COMPONENTS
Switching
regulator
q
q
q
w
w
