Janome J30 - Front Cover

6
CHANGING EXTERNAL PARTS
FRONT COVER
To remove:
1.Removethefacecoverandfree-armcover(Seepage4and5).
2.Removethesetscrewsq(2pcs.).
3.Removethesetscrewsw(4pcs.),backcovere.
4.Removethesetscrewsr(2pcs.).
5.Loosenthesetscrewt.
6.Disengagethefrontcoverandrearcoverhooks.
7.Removethefrontcover.
8.DisconnectalltheconnectorsfromthecircuitboardA.
NOTE:
Donotdisconnecttheconnectorsbypullingoncord.Todisconnect,grasptheconnector,notthecord.
To attach:
7.Followtheaboveproceduresinreverse.See"PRINTEDCIRCUITBOARDACONNECTION".(Page24)
q
w
w
e
w
r
r
t
