Janome J30 - Driving Motor (DC Motor)

29
DRIVING MOTOR (DC MOTOR)
TO REMOVE:
1. Removethefrontcover.(Seepage6.)
2. Removethesetscrewsq(2pcs.),setscreww(1pcs.),thedrivingmotorandthebelt.
TO ATTACH:
1. Installthedrivingmotorandthemotorbelt.Tightenthemwithsetscrewsq(2pcs.) lightly.
2.Movethemotorupordowntoadjustthemotorbelttension.
 Thebeltshoulddeect5mmwhenapplying200gramsofloadtothemiddleofthebelt.
 Tightenthesetscrewsq(2pcs.)rmly.
3. Securethecablesusingthenylonclipandtightenthesetscreww .
4. Attachthefrontcover.
REPLACING THE ELECTRONIC COMPONENTS
200gpressure
5 mm
q
DCmotor(unit)
Belt
qw
Nylonclip
