Janome JUNO E1030 - Clearance Between Needle and Tip of the Rotary Hook

12
Adjustment procedure:
1.Removethefacecover.(Refertopage4).
2.Removetheneedleplateandbobbinholder.
 Attachthemasterneedle.
 Turnthepowerswitchon.
 Selectthezigzagstitch,andsetthestitchwidthto“5.0”.
3.Removetheneedleplateandbobbinholder.Replacetheneedlewiththemasterneedleandtightenthe
 needleclampscrew.
4.LoosenthesetscrewsA(2pcs.)andmovethepresserbarbaseplateinthedirectionofthearrows(BorC).
*MovethepresserbarbaseplateinthedirectionofBwhentheclearanceistoolarge.
*MovethepresserbarbaseplateinthedirectionofCwhentheclearanceittoosmall.
 Adjusttheclearancebetweeentheneedleandhookbetweeen-0.10to+0.05mm.Tightenthesetscrews.
*Theedgeofpresserbarbaseplateshouldalwaystouchesthebosseswhileadjustingtheclearanceit.
5.Attachthebobbinholderandneedleplate.Attachthefacecover.
NOTE:
Besurethattheclearancebetweentheneedledroppositionandtheedgeofneedleshouldbe0.2mmmore
forbothsides(Refertopage9).
*Theclearancebetweentheneedleandthepointofhookshouldbe–0.10to+0.05mm.
CLEARANCE BETWEEN NEEDLE AND TIP OF THE ROTARY HOOK
MECHANICAL ADJUSTMENT
Boss
Needle plate
Setscrew
SetscrewA
DirectionB
DirectionC
Bobbinholder
Needleclampscrew
–0.10to+0.05mm
Tipofhook
Masterneedle
