MECHANICAL ADJUSTMENT
STRETCH STITCH FEED BALANCE
To check:
1. Turnthepowerswitchon.
 Besurethefeedbalancingdialissetatstandardpositionasshownbelow.
2. Selectthetriplestitch“”(stitchpattern#05).
3. Sewthe15piecesoftriplestitchasshownbelow.
 Besurethatthetotalstitchlengthfromthe3rdpieceto13thpieceiswithintherangeof25to27mm.
 Ifnot,adjustasfollows;
To adjust:
4.Removethecap.
•Turnthehexagonalsocketscrewinthedirectionof(A)ifthetotallengthof10piecesofthetriplestitch
 patternisshorterthan25mm.
•Turnthehexagonalsocketscrewinthedirectionof(B)ifthetotallengthof10piecesofthetriplestitch
 patternislongerthan27mm.
5.Sewthetriplestitch15piecesagainaftertheadujsutment.
 Besurethatthetotalstitchlengthfromthe3rdpieceto13thpieceiswithintherangeof25to27mm.
 Attachthecap.
Feedbalancingdial
(Standardposition)
Hexagonalsocketscrew
Cap
(A)(B)
Turnthepowerswitchon. TheLEDdisplaywill
indicate“
0
1”.
Pressthestitchlength
adjustingkey 4 times to
displaythe“05”.
Pressthe start/stop
button .
Feedlaguratorplate
Sewthetriplestitch15piecesagainafter
theadujsutment.
25 to 27 mm
