PRINTED CIRCUIT BOARD A CONNECTION
NOTE:
Donotdisconnecttheconnectorsbypullingoncord.
Todisconnect,grasptheconnector,notthecord.
REPLACING THE ELECTRONIC COMPONENTS
(Notapplicableforthismachine)
Printed circuit board L (White)
Printed circuit board P (Black)
Switching ragulator (White)
ErP switch (Red)
Feed motor (White)DC motor (White)
Bobbin winder switch (Blue)
Presser foot lifter switch (Green)
Foot contorol (Black)
Zigzag width motor (Green)
Connector for writing program (Not used normally.) (White)
