Janome JUNO E1030 - Driving Motor (DC Motor)

26
DRIVING MOTOR (DC MOTOR)
TO REMOVE:
1. Removethefrontcover.(Refertopage6.)
2. Removethesetscrews(2pcs.)andthedrivingmotorandthebelt.
TO ATTACH:
3. Installthedrivingmotorandthemotorbelt.Tightenthemwithsetscrews(2pcs.) lightly.
4.Movethemotorupordowntoadjustthemotorbelttension.
 Thebeltshoulddeect7to9mmwhenapplying300grams-forceofloadtothemiddleofthebelt.
 Tightenthesetscrews(2pcs.)rmly.
5. Attachthefrontcover.
REPLACING THE ELECTRONIC COMPONENTS
300gfpressure
Setscrew
7 to 9 mm
DCmotor(unit)
Belt
Setscrew
