SWITCHING REGULATOR UNIT
TO REMOVE:
1. Removethefrontcoverandtherearcover.(Refertopages6and7.)
2. Removethesetscrews(3pcs.)andtheswitchingregulatorwithcords.
TO ATTACH:
3. Followtheaboveproceduresinreverse.
 Besuretoconnecttheconnectors(switchingregulatorconnector(white)andErPswitchconnector(Red))to
 thecircuitboardA(Refertopage23).
*ErPswitch(Red)isonlyfortheapplicablemodel.
REPLACING THE ELECTRONIC COMPONENTS
Switching
regulator
Setscrew
Setscrew
Setscrew
