Janome JUNO E1030 - Printed Circuit Board A

24
PRINTED CIRCUIT BOARD A
TO REMOVE:
1. Removethefrontcover.(Refertopage6.)
2. PulloutconnectorsfromtheprintedcircuitboardA.
3. Removethesetscrews(4pcs.)andtheprintedcircuitboardA.
TO ATTACH:
4.Followtheaboveproceduresinreverse.
NOTE:
Donotdisconnecttheconnectorsbypullingoncord.
Todisconnect,grasptheconnector,notthecord.
REPLACING THE ELECTRONIC COMPONENTS
PrintedcircuitboardA
Setscrew
Setscrew
PrintedcircuitboardL
Setscrew Setscrew
