 This setting will supply
fresh water to all xtures in the RV from a pressurized
water source attached to the utility center panel.
1. Utility center valve should be set to  
 position (pointing down).
2. White valve should be pointing toward the pump
as shown.
3. Black valve should be pointing toward the pump
strainer as shown.
The pump is  used to supply water to xtures when a pressurized water source is attached
to the utility center city water inlet.
This setting will ll the water tank from a pressurized
water source attached to the utility center panel.
1. Set the blue CITY WATER / TANK FILL valve
at the utility center to the   position
(horizontal) pointing to the left (as shown).
2. Water valves at the water pump should be in the
positions.
3. Black valve pointing to the pump strainer, white
valve pointing to the left (toward the water tank).
4. Attach a fresh water hose to the fresh water con-
nection inlet on the panel. The other end of the
hose should be attached to a pressurized fresh wa-
ter source.
5. Turn on the pressurized water to ll the fresh water tank. The 12V pump is used
for this feature (water tank drain valve must be closed).
6. When the water tank is full, turn o the water source and disconnect the hose from the
water source, the disconnect from the panel. Set the blue lever to the 
position.
7. Return the valves at the water pump to the  positions.

This setting will allow sanitizer or antifreeze into the water lines (but not the water tank).
 White valve should be pointing toward the pump
as shown.
 Black valve should be pointing toward the clear
suction hose.
 Place the clear hose into a container of sanitizer solution (or antifreeze if winterizing).
Turn the pump ON, and sanitizer or antifreeze will be drawn out of the container and into the
water lines. Refer to Sanitizing the Plumbing System or Winterizing the Plumbing System.
Refer to the (2) Valve Water Heater Bypass section as

 Utility center blue valve posi-
tion does not matter as it is not used for
sanitizing or winterizing.
