190
The label shown here is located next to the slide out controls
inside the entrance door.
Remove the straps holding the mattress to the bed frame by
unsnapping the two plastic buckles on top of the mattress.
These straps can be stored on the side of the mattress, or
tucked between the headboard and the mattress. Release the
mattress hook from the foot of the bed.
Attach the “Y” strap that holds the mattress to the bed-
frame. Pull the straps with the buckles up from the
head of the bed and snap them to the “Y” strap. Secure
the snap hook at the footboard.
Unhook the safety strap snap hooks from the steel loops on
the arms of the sofa.
Release the locking lever (if applicable) so bed can be
raised.
Push the bed back up into the storage position.
Failure to attach these snap hooks to the steel
loops on the sofa can result in serious injury or property damage.
On some models, the Murphy bed may lock in place when
lowered to keep it from ipping up unexpectedly. In order to release the
bed, a lever must be pulled rst. There are two types of levers. One is a
“T” handle installed in the side dresser and the other is a lever built into the
side of the couch. When the lever is pulled, the bed can be returned to the
folded or stored position. Make sure to latch the sliding “D” bolts on each
side when bed is returned to the upright stored position.
