VTX A8 | Rigging Manual
7.2 INSTALLING THE TOP PART OF THE VTX A8 VT
The VT-TOP connects to the top cabinet of an A8 stack to form a robust and defined footprint that stabilizes the carts during trans-
portation. The flat top allows other gear to be stacked on top of A8 arrays traveling on VTX A8 VT carts for a more efficient truck pack.
STEPS:
• Lower the VT-TOP onto the top VTX A8 cabinet. Be sure the four rigging corners of the A8 cabinet engage with the VT-TOP.
• Secure the VT-TOP by installing the four quick release pins onto the top VTX A8 cabinet.
1
2
1
2
