41
VTX A8 | Rigging Manual
STEPS:
• Check that all red Locking Levers are in the locked position, then engage the hoist to lift the array off the ground. As the hoist
lifts, each cabinet will expand to the correct angle. As each cabinet reaches the correct inter-enclosure angle , it stops ex-
panding.
• When all cabinet angles are set, and the array is suspended a short distance off the ground, disconnect the Vertical Transporter
by removing the two rear quick release pins, followed by the front pins.
9.3 SUSPEND THE FIRST STACK
1
2
1
2
To Next Page
