VTX A8 | Rigging Manual
13.6 MINI FRAME AND RC500
The Mini Frame can be used in combination with the VTX RC500 rotating clamp. The VTX RC500 is a universal truss/pipe adapter
designed for vertically suspending speaker arrays from standard truss structures or pipes. The RC500 supports arrays of up to 500 kg
(1,100 lbs) and is compatible with array frames that support ½-inch shackles, such as the VTX A8 MF. The RC500 is attached to the
center shackle position of the Mini Frame and allows for 360 degree rotation. For more information on the RC500, refer to the RC500
User Manual.
CAUTION: Array weight must always be within the 500 kg capacity of the RC500. For more information on mechan-
ical limits and use cases refer to the RC500 User Manual.
