JBL VTX Series - Close Angle Locks and Move Pins to Storage

43
VTX A8 | Rigging Manual
STEPS:
• After the two front QRPs have been secured, lower the flown array until the two rear connection points join together. Once
touching, insert the two rear QRPs to secure the clusters together. If the angle of the flown cluster is too steep (too much down-
tilt) and the rear connection points are too far apart, follow the steps shown below to safely connect the clusters.
1
