51
VTX A8 | Rigging Manual
STEPS:
• Use the electric hoists to raise the B18s off the ground.
• Once suspended, remove the VT by first removing the front two QRPs and then the two at the rear.
• Restore the two rear QRPs to their storage positions. The front and mid QRPs should remain free for attaching the first A8
cabinet.
1
2
3
CAUTION: All six quick release pins and rigging arms should always be used when connecting one B18 subwoofer to
another. Under no circumstances should any pin be left unused. A8 cabinets can only be attached to the B18 rigging
points corresponding to those connected to the array frame. Normally, these are the four forward most connection points.
With the frame properly connected, lift the B18 off the ground and disconnect the Vertical Transport cart.
Cable Strain Relief
To Next Page
