JBL VTX Series Rigging Manual

75
VTX A8 | Rigging Manual
STEPS:
• Select the desired inter-cabinet angle for the first A8 and extend the rigging arm to set the angle on the first A8.
• Stack the next A8 on top, pin the cabinets together, and set the angle for the next cabinet.
• Repeat steps 3 and 4 as needed to assemble the full array.
3
4
5
3
4
5
