VTX A12 | Rigging Manual
7.3 STORING THE VTX A12 VT
Once the system has been deployed, the VT-TOP can connect to the VTX A12 VT for storage. After the two are connected, several as-
semblies can be stacked together for storage.
STEPS:
• Line up the corners of the VTX A12 VT and the VT-TOP. Lower the VT-TOP on to the VTX A12 VT until all four corner connection
points engage.
• Use the four quick release pins found on the VT-TOP to secure it to the VT.
TIP: The VTX A12 VT CVR Cover can be stored in the empty space between the VT and VT-TOP. Fold the cover and place
it in the VT before pinning the VT-TOP.
