38
VTX A12 | Rigging Manual
STEPS:
• Ensure that all red Locking levers are in the locked position, then engage the hoist to lift the array off the ground. As the hoist
lifts, each cabinet will expand to the correct inter-enclosure angle, and the sound of pins sliding past locking points will be
heard. Each cabinet will stop expanding when it reaches the correct inter-enclosure angle.
• When all cabinet angles are set and the array is suspended a short distance off the ground, disconnect the Vertical Transporter
(VT) by removing the two rear quick release pins, followed by the front pins. The array should not be so high in the air that the
Vertical Transporter swings freely.
9.2 SUSPEND THE FIRST STACK
1
2
1
2
