VTX A12 | Rigging Manual
10 - DISASSEMBLING AN A12 ARRAY
Carefully follow the steps in this chapter to correctly and safely disassemble an array.
STEPS:
• To desuspend an array of VTX A12 cabinets, begin by safely lowering the entire array to a working height.
• Press the Release Buttons to open the red Angle Lock mechanisms for the lower four cabinets. This allows the bottom four
VTX A12 cabinets to collapse back to the 10-degree position.
• Attach the Vertical Transporter to the bottom cabinet. Lift the VT by the round bar at its rear and connect the rear attachment
points with quick release pins, then lift the front of the VT and use QRPs to attach it at the front of the VTX A12 cabinet.
10.1 OPEN THE ANGLE LOCKS AND ATTACH THE VT
1
2
1
2
3
3
