JBL VTX Series User Manual

67
VTX A12 | Rigging Manual
STEPS:
• Select the inter-enclosure angle for the first A12 and extend the rigging arms to set the angle.
• Stack the next A12, pin the cabinets together, and set the angle for the cabinet. Repeat steps 3 and 4 to add the remaining
cabinets to the array.
3
4
TIP: The very top cabinet does not require an angle when used in ground-stacked configurations. It’s best to set the angle
to the 10-degree position for the best appearance.
3
4
