SERVICING AND MAINTENANCE 419
F68 – – Spare*
F69 – – Spare*
F70 – 25 Amp Clear INJ/IGN COIL (GAS)/GLO PLUG MOD (DSL)
F71 – – Spare*
F72 – 10 Amp Red HD ELEC ACC PKG*
F73 – – Spare*
F74 – – Spare*
F75 – – Spare*
F76 – 20 Amp Yellow ECM (GAS)/PCM (DSL)
F77 – 10 Amp Red Heated Mirrors
F78 – – Spare*
F79 – 20 Amp Yellow SMART BAR CTRL MOD
F80 – 15 Amp Blue
Powertrain Control Module (PCM)/Solenoid 1 2 Block
S
h
ift
F81 30 Amp Pink – REAR DEFROSTER (EBL)
F82 30 Amp Pink – FUEL HTR*
F83 60 Amp Yellow – GLOW PLUG*
F84 30 Amp Pink – UREA HTR CTRL UNIT*
F85 – 10 Amp Red PM SENSOR*
F86 – – Spare*
F87 – 10 Amp Red SUPPLY/PURGING PM*
Cavity Cartridge Fuse Micro Fuse Description
