420 SERVICING AND MAINTENANCE
F88 20 Amp Blue – NOx SENSOR #1/#2*
F89 – 10 Amp Red
Steering Column Control Module (SCCM)/Cruise Control
(C
RUISE CTL)/Digital TV (DTV)/Airbag Disable Lamp
F90 20 Amp Blue – TRAILER TOW PARK LMP*
F91 – 20 Amp Yellow Horn
F92 40 Amp Green – HD ACCY #2*
F93 40 Amp Green – HD ACCY #1*
F94 – 10 Amp Red Tire Pressure Monitor (TPM)/RF Hub system (CORAX)
F95 – – Spare*
F96 – 10 Amp Red PWR MIRROR SW
F97 – 20 Amp Yellow RADIO/TBM
F98 – 10 Amp Red SW BANK-HD ELEC/OFF ROAD
F99 – – Spare*
F100 30 Amp Pink – ESC-ECU & VALVES
F101 30 Amp Pink – Drivetrain Control Module (DTCM)
F102 – 15 Amp Blue DUAL USB PORT
F103 – 15 Amp Blue HD ACCY #3*
F104 – – Spare*
F105 – 10 Amp Red
Integrated Center Stack (ICS)/Heat Ventilation Air
C
o
nditioning (HVAC)
F106 50 Amp Red – Electronic Speed Control (ESC)/PUMP MTR
Cavity Cartridge Fuse Micro Fuse Description
