424 SERVICING AND MAINTENANCE
Bulb Replacement
NOTE:
Lens fogging can occur under certain atmo-
spheric conditions. This will usually clear as
a
t
mospheric conditions occur to allow the
condensation to change back into a vapor.
Turning the lamps on will usually accelerate the
clearing process.
Halogen Headlamps
NOTE:
We advise referring to an authorized dealer for
se
rvice.
See below steps to replace:
1. O
pen hood and support using prop rod.
2
. Remove the front grille. Turn the retainers
a
long the top a quarter turn counter-
clockwise and remove.
3. P
ull the bottom of the grille away, starting at
o
ne side and working toward the other.
4. Remove the three screws holding the
h
eadlamp to the vehicle.
5. Remove lamp from the vehicle.
6
. Remove the lamp from the collar.
7
. Grab the bulb and turn a quarter turn
c
ounterclockwise.
8. Pull the bulb from the housing.
9
. Push connector locking tab to the unlock
p
osition.
10. Remove connector from bulb.
1
1. Push connector onto new bulb base, and
p
ush the connector locking tab to the lock
position.
12. Reinstall bulb housing. Rotate the bulb a
q
uarter turn clockwise.
Front Park/Turn Signal
NOTE:
We advise referring to an authorized dealer for
se
rvice.
See below steps to replace:
1. R
emove the front wheel liner fasteners to
a
ccess bulb sockets.
Wheel Liner
CAUTION!
Do not touch the new bulb with your fingers.
Oil contamination will severely shorten bulb
life. If the bulb comes in contact with any oily
surface, clean the bulb with rubbing alcohol.
