·5·
2 Installation
2.1 Prepare Installation Tools
The following tools will be needed in inverter installation and wire connection.
Crimp the PV cable core in
connector tube for PV
connector.
Used for drilling holes for
installation bracket.
Used for AC side wire
installation
Used for installing and
disassembling inverter cover
2.2 Installation Direction and spacing dimension
The inverter shall be installed vertically or tilted backwards with a maximum
angle of 10°
The minimum installation spacing dimensions are shown below:
