·7·
3 Electrical Connection
3.1 Connecting Terminals of Inverter
The input and output terminals are shown as below:
PV array
GPRS antenna
Water level
sensor
Water pump
RS485 module
Solar pumping inverter
Grid
Terminals Description
Terminals
Description
PV
PV array DC positive input terminals(PV+、PV-)
