·26·
100cm
100cm
100cm
100cm
100cm
100cm
100cm
Figure5-2 Minimum spacing of adjacent installations
Table5-1 Minimum spacing dimension
8.3 Installation of Inverter
Notice！
Do not use jackbolts or screws to install inverters on rocks or panels.
Notice!
● Fix the inverter on the rock or panel with the toggle bolt or screw is not permitted.
● Supplier would provide the bolt which suitable for the installation on the concrete
wall.
● If the inverter is fixed on the wooden wall, please choose suitable bolt to finish the
installation, the bolt length should be enough and penetrate the 1/2 depth of the
walls.
