MNP11M01GB06 May 2007- Rev.4 Page: 11 de 40
1.- To connect the cable comunications RS-232 to the output RS-232 from de
compact.
2.- To do the next steps:
a) To copy the programme that We want to record in the subdirectory \ J2000
of the directory where is the programme REPROYYXX.EXE.
b) Execute the programme REPROYYXX.EXE ( YY letter mean the language and
XX mean the version). Enter in option FLASH-GRABAR-J2000, choose the
programme to record with extension H00, the other programme with extension
H01 will be loaded automatically.
3.- To connect supply to the compact from the machine.
4.- When the recording had finished in the screen of the computer appears J2000
RECORDING.
• RECORDING FRON THE CARD READER:
To recording the programme from the card reader it is neccessary to have the next
components:
* Recording card of 128 K, cod : 8590052.
* Tabletop card reader with the current version
1.- To copy the programme of extension H00 and H01 in the subdirectory \
j2000 in the directory where is the programe REPROYYXX.EXE.
2.- To load in the card the programe to be recorded, to do this execute the programe
REPROYYXX.EXE and in the menu choose TARJETA-GRABAR-J2000, and choose
the programe to be loaded.
3.- To connect the card reader to the compact.
4.- Introduce the card in the card reader.
5.- To connect the compact to supply.
6.- To begin the recording, and the two leds of the card reader will be switch off and
switch on alternately. When the red led is switch on only, the programming has
finished.
Using the selection buttons and the programming display.
The J-2000 compact has two operating modes, the coin acceptance and refund mode
and the program mode. In the first the compact is ready for the machine to carry out
sales (sell mode), in the second the operating options of the J-2000 can be modified
(program mode).
This compact has a 4 digit display and 4 selection buttons integrated
in the separator block, which allow the selection and visualisation of
the different addresses and their contents.
In sell mode the decimal points of status (thousands and hundreds)
that light alternately permitting the visualisation of the dynamic status
of the J-2000.
