QUANTUM™ HD COMPRESSOR CONTROL PANEL
MAINTENANCE
090.040-M (MAR 12)
Page 54
STATUS - Panel (ModBus TCP Log)
ACCESSING:
Panel ModBus TCP Log
DESCRIPTION: The screen shown above represents the
ModBus communications packages that have been sent or
received from all serial communications, viewable at one
time. This is an informational screen only.
DESCRIPTION: This screen is for informational purposes
only, as there is nothing that can be changed. The data
that is populated here is received via serial communica-
tions from an optional DBS Solid State drive unit.
STATUS - DBS Starter Info
ACCESSING:
Panel DBS Starter
(If
Used)
(If
Used)
