1/7/2021 PDF Export

https://docs.johnsoncontrols.com/bas/internal/api/webapp/print/b4118696-0b8a-4733-98fb-fdd04b065b15 52/60

12. Connect the USB 2.0 A Male to Micro USB 5 pin Male Cable to the FIT. See

Figure 33.

13. Remove the programming jumper W6 located on the FIT to the left of the

power switch and turn the FIT power switch to the On position.

Figure 10. W6 Jumper and Power Switch
