Main Menu Buttons - Settings
The integral humidity sensor may be calibrated -20% to +20% RH
Calibrate Sensors
(0˚)
The thermostat and wired sensor may be calibrated -7 to +7 degrees F.
•
Thermostat
•
Wired Sensor
•
Humidity
The installer or service
technician can use this
feature to test the
functions without any
time delays of the
thermostat.
Test Outputs
With a 1st stage cooling call, Y1 and G are active
