The ColorDisplay Desktop App
Uploading Photos and Settings to your thermostat
Import Settings from SD Card
When you are finished adding and editing photos and settings,
click on Save to SD. When prompted, remove the SD card
from the SD card reader on your computer.
Save to SD
SD Card
Slot
At the thermostat:
Press
then
Settings
SD Card
Insert the SD card into the SD Card Slot.
Next, press
Press
Then press
Select the items to import into your thermostat then press
NEXT
Yo ur thermostat will automatically save your new photos and
settings in its internal memory. When finished, you may remove
the SD card. It is not needed for normal thermostat operation.
*NOTE: A 2GB SD card
is recommended.
MENU
