JOHNSON CONTROLS
FORM 145.05-NOM1 (708)
Continued on next page
TABLE 18 – BACnet MS/TP points (CONT.)
Point ID Point Description
Variable
Type
Read ( R )
Write ( W )
Value
Range
(Analog
Only)
Unit
(Analog
Only)
Instance
Number
Comments
VPHtMod
Status of the Analog Value of
the Output to the Modulating
Heat Valve in %
BAV R 16803
Only with
Modulating Heat
VPO/AMod
Status of the Analog Value
of the Output to the Air Side
Economizer Damper in %
BAV R 16803
Only with Air Side
Economizer Units
WEDNSDAYSCHED1
Turns Wednesday On / Off for
Schedule 1:
1 = On – Active
0 = Off – Inactive
BBV R/W - - 876
WEDNSDAYSCHED10
Turns Wednesday On / Off for
Schedule 10:
1 = On – Active
0 = Off – Inactive
BBV R/W - - 976
WEDNSDAYSCHED11
Turns Wednesday On / Off for
Schedule 11:
1 = On – Active
0 = Off – Inactive
BBV R/W - - 987
WEDNSDAYSCHED12
Turns Wednesday On / Off for
Schedule 12:
1 = On – Active
0 = Off – Inactive
BBV R/W - - 998
WEDNSDAYSCHED13
Turns Wednesday On / Off for
Schedule 13 :
1 = On – Active
0 = Off – Inactive
BBV R/W - - 1009
WEDNSDAYSCHED14
Turns Wednesday On / Off for
Schedule 14:
1 = On – Active
0 = Off – Inactive
BBV R/W - - 1020
WEDNSDAYSCHED15
Turns Wednesday On / Off for
Schedule 15:
1 = On – Active
0 = Off – Inactive
BBV R/W - - 1030
WEDNSDAYSCHED16
Turns Wednesday On / Off for
Schedule 16:
1 = On – Active
0 = Off – Inactive
BBV R/W - - 1041
WEDNSDAYSCHED2
Turns Wednesday On / Off for
Schedule 2:
1 = On – Active
0 = Off – Inactive
BBV R/W - - 887
User Interface Control Center
