TABLE 18 – BACnet MS/TP points (CONT.)
Point ID Point Description
Variable
Type
Read ( R )
Write ( W )
Value
Range
(Analog
Only)
Unit
(Analog
Only)
Instance
Number
Comments
VLALOut
This is the Status of Binary
Value of the Output to the
Alarm Output:
1 = Alarm – Active
0 = No Alarm – Inactive
BBV R - - 15610
VLB/P Mod BAV 16803 Not Applicable
VLB/PMod
Status of the Analog Value
of the Output to the Bypass
Damper in %
BAV R 16803
Only with FlexSys
Units
VLBoxOpn
Status of the Binary Value of
the VAV Boxes Output:
1 = Active
0 = Inactive
BBV R - - 15605
VLC/WMod BAV - - 16115 Not Applicable
VLCompA BBV - - 15606 Not Applicable
VLCompB BBV - - 15607 Not Applicable
VLCompC BBV - - 15608 Not Applicable
VLCompD BBV - - 15609 Not Applicable
VLCVEn
Status of the Binary Value of
the CV Fan Output:
1 = On – Active
0 = Off – Inactive
BBV R - - 15601
VLE/Wmod BAV - - 16804 Not Applicable
VLFanOut
Status of the Binary Value of
the Output to the Fan:
1 = On – Active
0 = Off Inactive
BBV R - - 15603
VLHtS2Cl
Status of the Binary Value of
the Output to the First Stage
Heat or Close for Tristate Heat:
1 = ON
0 = Off
BBV R - - 15611
VLHtS2Op
Status of the Binary Value of
the Output to the First Stage
Heat or Open for Tristate Heat:
1 = ON
0 = Off
BBV R - - 15612
VLPmpOut
Status of the Binary Value of
the Output to the Pump:
1 = On – Active
0 = Off Inactive
BBV R - - 15603
VLVAVEn
Status of the Binary Value of
the VAV Fan Output:
1 = On – Active
0 = Off – Inactive
BBV R - - 15602
6
