ZFR1800 Series Wireless Field Bus System Technical Bulletin10
ZFR1811 Router
A ZFR1811 Wireless Field Bus Router is used with any model FEC, IOM, or
VMA16 field controller to provide a wireless interface between a field controller
and:
• the NAE/NCE supervisory controller (by means of a ZFR1810 Coordinator)
• its associated WRZ Series Sensors
The ZFR1811 Router can also be used as a repeater to extend the range of the data
communications within the wireless mesh network, or to fill any gaps within the
mesh network, based on the physical layout of the wireless devices, obstacles, and
other characteristics of the installation site.
A ZFR1811 Router is powered directly from the connected field controller’s
15 VDC output. It can also be powered by the ZFRRPT repeater accessory to serve
as a stand-alone repeater, extending the range of the BACnet data communications
within the wireless mesh network.
Supported Field Controllers
The ZFR1800 Series Wireless Field Bus System enables wireless BACnet
connectivity between FAC, FEC, IOM, or VMA16 controllers and Network
Engines, including NAE/35/45/55 and NCEs.
In addition, the wireless field bus system provides wireless communication
between FEC, FAC, or VMA16 Controllers and WRZ Series Sensors. Each
wireless-enabled FEC, FAC, or VMA16 controller can support up to nine WRZ
Series Sensors, for multi-zone or averaging applications, or for high/low
temperature or humidity selection within a zone.
Note: The ZFR1811 Routers should be at the same Metasys system release
version as the wirelessly enabled FEC, IOM, or VMA16 field controller. If
there is a version mismatch, the Controller Configuration Tool (CCT)
provides indication of this, and the ZFR1811 Router automatically updates
during the main code download to the field controller. For information on
uploading or downloading the devices to match, refer to the Loading
Devices chapter of the Controller Tool Help (LIT-12011147).
Note: Some field controller applications do not support the occupancy/
temperature setback function.
Note: Wirelessly enabled FEC, FAC, and VMA16 field controllers can also use
hard-wired NS Series network sensors.
