ZFR1800 Series Wireless Field Bus System Technical Bulletin32
Installing the ZFR1811 Router as a Repeater
To install the ZFR1811 Router as a repeater:
1. Select a mounting location for each ZFR1811 Router that is to be used as a
repeater. Refer to the job plans and see Location and Estimating Guidelines
and Designing and Planning the ZFR1800 Series Wireless Field Bus System.
2. Set the ZFR1811 Router PAN OFFSET Switch to match the ZFR1810
Coordinator PAN OFFSET according to the job plans (for example,
Floor 1 = 1, Floor 2 = 2, and so forth).
3. Mount each ZFR1811 Router to its power supply within the MS-ZFRRPT-0
accessory. Refer to the ZFR1811 Wireless Field Bus Router Installation
Instructions (Part No. 24-10325-10).
4. Connect the ZFR1811 Router to the power supply, but do not apply power.
Installing a WRZ Series Sensor
To install a WRZ Series Sensor:
1. Select a mounting location for the sensor. Refer to the job plans, the
WRZ Series Wireless Room Temperature Sensors Installation Instructions
(Part No. 24-10332-2), and see Location and Estimating Guidelines
and
Designing and Planning the ZFR1800 Series Wireless Field Bus System.
2. Place the Mesh application DIP switch overlay over the DIP switches. Refer to
the WRZ Series Wireless Room Sensors Installation Instructions
(Part No. 24-10332-2).
IMPORTANT: The PAN OFFSET switch setting must be the same for all the
ZFR1800 Series and WRZ devices on the same wireless mesh network.
IMPORTANT: To avoid interference, assign a unique PAN Offset to each
wireless network in a building. Using a unique PAN OFFSET is particularly
important if you have PANs on adjacent floors of a building. Do not use the
same PAN Offset on multiple wireless networks in a building, even if the
PANs do not overlap.
IMPORTANT: Do not connect the ZFR1811 Router to the power supply
before setting the PAN OFFSET switches.
