ZFR1800 Series Wireless Field Bus System Technical Bulletin 43
Connecting to and Downloading the FEC/FAC/IOM/VMA Field Controllers
To connect to and download the FEC/FAC/IOM/VMA Field Controllers:
1. Start CCT on your computer and connect to the ZFR1800 Series Wireless Field
Bus System by one of the methods shown in Table 9.
2. Scan the FC Bus for WEFCs using CCT.
3. Identify the WEFCs to configure and download using CCT or the Point
Schedule.
4. Download the Controller Application File (CAF) for each WEFC controller
using CCT or the Point Schedule.
5. Write additional configuration parameters to the FEC/IOM/VMA field
controllers using CCT or the Point Schedule Parameter Sheet.
Verifying Wireless Operation
To verify wireless operation:
1. Open Microsoft® Internet Explorer® Web browser and log on to the
NAE/NCE using the Metasys Site Management Portal.
2. From the Metasys Site Management Portal, perform a discovery of the MS/TP
trunk.
3. Verify that all the FEC/IOM/VMA field controllers (wired and wireless) have
been discovered.
Note: When you first power up the wireless network, there is a potential for a few
field controllers to toggle online and offline for a short period until the
entire trunk has finished its startup procedure. This is a normal operation.
Table 9: Connection Points for Configuring Wireless-Enabled
FEC/IOM/VMA16 Field Controllers
MS-BTCVT-1
at Hard-wired
FC Bus
1
1. For information on using the MS-BTCVT-1 to connect to FEC/IOM/VMA16 field controllers,
including when to use the MS-ZFRCBL-0 wire harness, see Figure 10 and Figure 12 and
refer to the Wireless Commissioning Converter Installation Instructions (Part No. 24-10108-
2).
MS-BTCVT-1 at
Wireless
FEC/IOM/VMA
1
ZigBee Wireless
Connection
in CCT
2
2. At Release 4.0, the ZigBee connection type within CCT requires the CCT patch that is
available on the Release 4.0 Branch Purchase Package, and the USB adapter with ZigBee
driver. At Release 4.1 or later, the ZigBee connection type within CCT requires the USB
adapter with ZigBee driver. See WRZ-SST-120 Wireless Sensing System Tool
.
Downloading Application
(via CCT or Point Schedule)
X
3
3. This action via CCT is accomplished through CCT connected directly to the hard-wired FC
Bus or through NAE passthrough.
XX
Downloading Boot and Main
Firmware
(via CCT or Point Schedule)
X
3
X
Downloading Parameters
(via Point Schedule)
XX X
