JRC JAN-7201 - 1 Route Planning; Starting the Route Planning

7
1 Route Planning
To create the route, enter the waypoint (WPT) by the following two methods.
Table Editing Mode：the way to enter each WPT’s value into the table
Graphic Editing Mode：the way to plot each WPT on the chart graphically by using the mouse
In this quick reference, the following logos indicate the type of these modes.
・ : Table Editing Mode
・ : Graphic Editing Mode
1.1 Starting the Route Planning
1 Click on the [Menu] button on the left tool bar.
The top menu is displayed.
2 Click on the [Route Planning] button on the top menu.
The [Route Planning] dialog box appears on the screen.
G
T
T
G
