2.5 Setting up the Dragging Anchor Alert
1 Click on the [Menu] button on the left tool bar.
The menu is displayed.
2 Click on the [Anchor Watch] button on the menu.
The [Anchor Watch] dialog box appears.
The preview of dragging anchor monitoring area that was set is displayed (broken line).
When the dialog is displayed, the anchor position is placed at the center of the circle.
3 Set dragging anchor monitoring to ON by clicking on the [Monitoring Anchor] button.
Dragging anchor monitoring starts based on the setting.
The dragging anchor monitoring area on the chart is changed to a solid line.
When own ship exits from the dragging anchor monitoring area, the "Dragging anchor" alert is
displayed.
Click on the [Monitoring Anchor] button and turn off button indication.
Finish the dragging anchor monitoring.
