JUKI MO-2500 - Installation of the Throat Plate

–
12
–
Standard adjustment
❸
❷
❶
9. Installation of the throat plate
WARNING :
To protect against possible personal injury due to abrupt start of the machine, be sure to start the
following work after turning the power o󰀨 and ascertaining that the motor is at rest.
Lower knife
(C)
1.4 mm
（
B
）
(A)
❶
Parallel
❹
Thread sliding
segment lever
ON
+ 0.6
- 0.2
Thread sliding
segment lever
OFF
* Thread sliding segment lever
(Selection lever for overlocking
or roll hemming)
