JUKI MO-2500 - Timing between Upper and Lower Looper

–
32
–
Standard adjustment
19. Timing between upper and lower looper
(B)
(A)
(A)
❶
❷
(C)
❶
❷
WARNING :
To protect against possible personal injury due to abrupt start of the machine, be sure to start the
following work after turning the power o󰀨 and ascertaining that the motor is at rest.
(B) 0.1 to 0.3 mm
(A) 1 ± 0.5 mm
(E)
(D)
